Packtech Automatic Carton Box Making Machine
PT-GPK-40H50
PI REQUEST FORMAnswered in 1 business day
Brand: | PACKTECH |
Product Code: | PT-GPK-40H50 |
Technical Details
- Minimum Product Dimensions : 200 mm x 150 mm x 100 mm
- Maximum Product Dimensions : 600 mm x 450 mm x 450 mm
- Capacity : 50 Box / Minute
- Tape Dimesions : 7.5 cm | 3 inch
- Used Tape Reel Length : 1200 Meter
- Carton Box Feeding Capacity : 100 Box
- Air Consumption : 450 NL / Minute
- Air Requirement : 6 Bar
- Motor : Servo Motor
- Machine Weight : 1200 kg
- Machine Dimensions : 3120 mm x 1410 mm x 1900 mm
- Power Requirement : 230V | 50-60 Hz | 1 PH
